JH-3V14G45-T2A-M370
LEDGUHON
| Quantity: | |
|---|---|
3W High Power UV 365-370nm Led
| Part No. | Wave length(nm) | Power(W) | Voltage(V) | Current(mA) | Optical power(mW) | Angle(deg) |
| JH-3V14G45-T2A-MDL370 | 365-370 | 3 | 3.2-3.6 | 700 | 800-1000 | 120 |
| JH-3V14G45-T2A-M370 | 365-370 | 3 | 3.2-3.6 | 700 | 1000-1200 | 120 |
Note:
Other wavelengths in the range of 360-1500nm can be customized according to requirements.
The luminous Angle can be customized to 60/120 degrees
UV curing lamp, nail lamp, scorpion lamp, mosquito killing lamp, insect inducing lamp, etc
